Hepa Filter Air Intake Box

The Filquip Hepa Filter air intake box is the ideal solution for providing clean air into your plant equipment process.

Developed for Fan and Vacuum Conveying intakes in industrial food processing plants the housing box is made from Stainless Steel with a pre-fitted outlet pipe spigot as requested by the customer.

Hepa Filter Air Intake Box

The Filquip Hepa box system comes with:

Air Intake box in 304 or 316 Stainless Steel
A premium washable V-form pre-filter (Rated resistance 65Pa up to a maximum 3400 m3/hr airflow)
AstroCel 3 Hepa Filter H13 (Rated resistance 250Pa up to a maximum 4000 m3/hr airflow)
This pre-filter and hepa-filter system provides an extended life with greater than 99.99% Efficiency at 0.3 Micron.

New Filquip Portable Vacuum Conveyor – FVC

Filquip has worked with the Coffee Roasting and Calcium Powders industries to develop a Mobile Vacuum Conveyor with wand piece to allow staff to suck powders and granules from the bags and lift them up into their equipment.

The FVC mobile vacuum conveyor can lift almost any powder or granule product from bags or containers using the vacuum wand and lift it up into equipment such as roasters, hoppers and mixers.

Many processes involve staff lifting heavy bags or drums of powder or granules into equipment. This exposes them to physical injury through incorrect lifting techniques or just lifting things that are too heavy. One of the easiest ways to mitigate this risk is to use vacuum conveying to lift the powder or granules up into the equipment.

Portable Vacuum Conveyor

Coffee Vacuum Lifting Conveyor

Manufactured from polished 304 stainless steel.
Food grade suction hose (Suitable for food and pharmaceutical industries).
The unit comes on lockable wheels for mobility around the facility.
The unit comes complete with in-built reverse pulse cleaning.
Simple control panel provided for ease of operator use.
Discharge height up to 2m.
Nominal throughput up to 6m³/hr for the largest models.
Available in Single Phase, Three Phase and Pneumatic motor configurations.

Open FVC Portable Vacuum Conveyor Brochure

Magnetic Separators and Tube/Pipe Magnets

The new Stif Magnetic Separators and Tube/Pipe Magnets are now available from Filquip including manual and automated metal disposal options for your system.

The automated magnetic separators work by magnetising metals contained in the product flow which become held to the side wall magnet, the side wall magnet flap then opens with the metals still magnetised, with the magnetic flap open over the discharge chute demagnetisation occurs depositing the metals into the waste chute.

The automated magnetic separators come in three standard sizes:

Chute Magnet

200mm x 350mm (Throughput 100 m3/hr)
200mm x 650mm (Throughput 200 m3/hr)
200mm x 950mm (Throughput 300 m3/hr)

The manual tube/Pipe Magnets are designed to intercept metals contained in the product flow and hold them to the magnetic body for cleaning and disposal. The tube or pipe magnets come in eight standard sizes:

100mm Diameter (Throughput 10 m3/hr)
150mm Diameter (Throughput 35 m3/hr)
200mm Diameter (Throughput 85 m3/hr)
250mm Diameter (Throughput 130 m3/hr)
300mm Diameter (Throughput 200 m3/hr)
400mm Diameter (Throughput 260 m3/hr)
500mm Diameter (Throughput 310 m3/hr)
600mm Diameter (Throughput 400 m3/hr)

Open the Magnetic Separators and Tube/Pipe Magnets Brochure

Eurac Borosilicate Glass Pipes and Bends

The new Eurac Borosilicate Glass Pipes and Bends come in a wide range of diameters. The transparency of the borosilicate glass allows simple visual checks of the material flowing through the pipes or bends. With Electrostatic Protection from its Copper Conductive Strip and Food Grade properties (think Pyrex Glass) they are well suited to a large range of products. Cleat Pipes

Borosilicate Glass has up to 10 times the abrasion resistance of Stainless Steel.
Available in multiple tube and pipe diameters including 38, 40, 45, 50, 60, 63.5, 65, 70, 76, 80, 84, 88.9, 101.6, 104 and 114mm. Non stocked sizes are available on special order.
Standard stocked sizes are sized to suit 2″, 2.5″, 3″ and 4″ Tube.
Available in Straight Lengths or 90 Deg Bends.

Open Eurac Borosilicate Glass Pipes and Bends

WAM Low Profile Circular Lump Breaker

The new WAM LBC Circular Lump Breaker is a low profile cost effective solution to clumps and lumps in powders and granular materials.

Circular Lump Breaker body manufactured in Aluminium Alloy and available with Stainless Steel or Mild Steel Blades.
Available in multiple diameters including 200, 250, 300, 350 and 400mm.
75mm Flange to Flange (Low Profile)
Comes with Gearbox and Motor

Circular Lump Breaker

New Dense Phase Conveying Brochure

Filquip has a new Dense Phase Conveying Brochure detailing the Sand Conveying advantages of a Dense Phase Conveying system for materials handling.

Detailing the different models that can be provided to convey almost any product at flow rates up to 100T/h and distances up to 500m. Dense phase systems are perfect for conveying hard to handle products and can be filled from Bulk Bag Unloaders, Silo’s, Hoppers, Chutes, Screw Conveyors and most other filling equipment types.

Some of the advantages include:

High product conveyed to Air used ratio = Energy saving and cost saving
Less moving parts = Reduced maintenance and costs
Lower velocity conveying = Lower pipeline wear = Reduced maintenance and costs
High Internal cleaning = Increased efficiency
Completely closed system = Increased safety
Reduced product stratification and impacts = Perfect for fragile and mixed materials

Open the Filquip Dense Phase Conveying Brochure

Savi Water Treatment Equipment Australia

Filquip is proud to represent Savi Water Treatment Equipment in Queensland, Australia.

The Savi range includes:

Rotating Drum Screens (Pre-MBR and Standard)
Screenings Washer Compactors
Grit Classifiers
Septage Recieval Stations
Pista Grit Circular Traps
Belt Screens
Step Screens
Mechanical Bar Screens
Band Screens
Sludge Thickeners
Travelling Bridges
Clarifier Bridges
Overflow Spillways
Penstocks
Sand Washers

The Savi Pre-MBR Rotating Drum Screen is the standard for solids capture to protect the plant membrane bio reactor, with over 15 operating screens across Australia and New Zealand.

Open Savi / WAM Water Equipment Brochure

Go to Filquip Page for Water and Waste Water Treatment Equipment

Silo Overfill Protection System – New Website Page

Filquip has a new Silo Overfill Protection Website page and Brochure available now. Overfill Protection Control Panel Silo Overfill protection Ducting to Ground

The Filquip overfill protection silo safety system consists of all the required items for ensuring the silo being filled cannot be over pressurized or overfilled and eliminates dust emissions:

Control panel – Available with key control to ensure the correct product is filled into the correct silo and with the ability to manage multiple silos.
Pinch valves – Controls and isolates different silo fill lines.
High level indicator – Provides feedback when the silo has reached a pre-set high level.
Differential pressure switch or electronic pressure meter – Measure in silo pressure.
Pressure Relief Valve (PRV) – Safety valve to release excess pressure in silo.
Dust collector – Venting of excess air without any dust emissions.
Ducting kit to vent to ground – Ducting from the PRV and Dust Collector to ground.
Wear bends/elbows – Abrasion resistant pipe bends and elbows for the silo filling lines.
Pneumatic fittings – Air regulators, fittings and airline required for pneumatic plumbing.

Open new Overfill Protection Webpage

IP Pressure Sensors for Tanker filled silos

Pressure Sensors for Tanker filled silos Filquip is proud to supply the Torex IPE Electronic Pressure Meter and IPM Mechanical Pressure Meter for monitoring of the pressure inside bins or silos during their filling from tankers and specifically during the purging of then tanker truck.

The pressure sensor membrane is self-cleaning and temperature resistant
The casing is aluminium alloy with IP55 protection rating.
Available with 4-20 mA output signal configurations for the IPE.
24VDC supply voltage.
IPX mounting spigot available for simple installation onto any silo

If your installing a new truck or tanker filled silo storage system or upgrading an existing silo system then the IPE/IPM Pressure meter is a key component for managing over pressurisation before the relief valve is activated, thus avoiding any emissions to the surroundings.

Open Torex IPE Pressure Sensor Brochure

Seperation of cement fines from reclaimed concrete truck wash water – Filquip Filter Press

Filquip has recently completed trials of its Filter Press units on the wash Removing suspended solids with filter press
out water from concrete trucks. The concrete returned from the job to the batch plant is washed out of the agitator truck into a pit or concrete reclaimer system (See WAM Consep concrete reclaimer). The wash water is separated from the sands and aggregates but contains suspended solids preventing it from being discharged to the sewer or re-used in concrete production.
