Filquip Lean Phase Pneumatic Conveying with WAM Equipment

Filquip is proud to supply lean phase positive pressure pneumatic conveying systems including quality components from WAM Group which we stock locally in Brisbane.

Filquip supplies the full range of equipment in the video including, Side Channel Blowers, Torex Rotary Valve, Wear Bends, WAM Dust Collectors, WAM Pressure Relief Valves and Torex Diverter Valves.

For more information please get contact our team.

View the Rotary Valves specifications datasheet and brochure

View the TOREX Diverter Valves specifications datasheet and brochure

View the SINT Wear Bends specifications datasheet and brochure

Belt Conveyor Dust Extraction System

Filquip was engaged by an engineering contractor to specify and supply a dust extractor for a belt transfer point at a quarry. The transfer point between the screen deck hopper and the belt transfer point generated dust clouds which traveled along the belt conveyor and into the screen house and then the local environment.

Filquip specified and supplied a FPHT.D.12 Filter Bag Dust Extractor with 2.2kw Fan Motor which was mounted on the belt transfer point to extract the dust generated and agglomerate it to larger/heavier particle sizes and return it to the belt.

Belt Conveyor Transfer Point Duct Extractor



Belt Conveyor Dust Extraction Systems

Air Slide Matting Available in Brisbane

Filquip carries Air Slide Matting Available in Brisbane off the shelf Ex Stock in standard 305mm, 350mm, 380mm, 415mm, 450mm and 500mm widths. We also carry crates with 10m long rolls of 1600mm wide Airslide matting and also 1600x1600mm squares to cut the silo air slide discs from.

We can also supply other custom air-slide requirements.

All of our Air Slide Matting Available Ex Stock is Quality Polyester Multifilament Fabric.

We can also supply special airslide materials for temperatures as low as -60 Deg C up to maximum temperatures of 250 Deg C with short periods up to 450 Deg C.

Air slide cloth

Our Air Slide Matting is used in:

  • Pneumatic Loading Systems.
  • Pneumatic Discharge Systems.
  • Air Slides.
  • Storage Silos.
  • Fluidising basins.
  • Railway Wagons Discharging Cones.
  • Tanker Trucks.
  • Isotainers.
  • Powder Coating Machine Sinter Basin Bottoms.
  • Powder Containers and many other applications.

Open Filquip Air Slide Matting Datasheet

Air Slide Matting Available in Brisbane

Office positive pressure filter unit for dust prevention

Filquip was engaged by a quarry to Design, Supply, Install and Commission a new office pressurisation unit to help prevent silica dust ingress into the site office.

The following features of the H1-V1 Office Pressurisation unit include:

  • 0.75kw pressurisation fan with dampner valve for throttling.
  • Sound dampening valves through the unit flow path to reduce noise transfer into the office.
  • Cyclone dust separation cell (600×600) to remove 90% of the dust from the quarry air and eject it before the air is then further filtered to a F9 rating, this significantly reduces the number of consumable filters used per annum to provide filtered air into the office.
    Office pressurisation unit for dust prevention

Office positive pressure filter unit for dust prevention

Office positive pressure filter unit

Long Radius Tube Bends SS304

Filquip is pleased to announce we are now stocking 304 stainless steel tube/pipe long radius bends available in 2”, 2.5”, 3” sizes (50.8mm, 63.5mm and 76.1mm Outside Diameters).

Supplied clean, deburred and wrapped with end caps ready for installation.

Open Filquip Long Radius Tube Bends SS304 Brochure

Stainless Steel Long Radius Tube Bends Ex Stock

Diameter 2” 2.5” 3”
50.8mm 63.5mm 76.1mm
Wall thickness 1.6mm 1.6mm 2.0mm
Angle α 90°
Radius R 500mm
Tail Length L1 200mm
L2 200mm
Pipe end Internal Chamfer



Size Part No.
Stainless Steel Bend 50.8mm BC5W05081505902
Stainless Steel Bend 63.5mm BC5W063515050902
Stainless Steel Bend 76.1mm BC5W076120050902
Available ex stock from Filquip in Brisbane



Filquip Deburred Stainless Steel tube bends

Bird Feed Granules Vacuum Loader

Filquip has Designed, Supplied and Installed a new vacuum loader system for a Bird Feed production facility to allow plant operators to convey the bird feed granules from bags at ground level up into the mill at the upper level without needing to lift or carry the bags up the stairs.

The FVC-1-Np Model was selected for the requirement which can load 0.8m3/hr of granules through the flexible hoses and wand into the SS304 body with automated reverse pulse cleaning system

Bird Feed Granules Vacuum Loader

Bird Feed Granules Vacuum Conveyor

Brewery Malt Grains Bulk Bag Unloaders

Filquip has designed, supplied, installed and commissioned a new set of two Bulk Bag Unloaders to handle brewery grains and further automate the brewery process. The Bulk Bag Unloaders have hoist systems that allow the brewers to load the bags of Wheat Malt and Rolled Wheat into the frames where they then discharge automatically through slide gate valves into the weigh hoppers on load cells.

The weigh hoppers each hold 800L of grain which is enough for multiple brews. When required the operators specify the weight of grain required and the load cells and rotary valve meter out the grain until the correct weight has been decanted into the conveyor below into the mill.

The following Filquip equipment package was provided for this Hazardous Area IECEX Brewery Bulk Bag Unloader System:

  • Two SBB-HFF Bulk Bag Unloaders with Monorail and Electrical Crane Hoists
  • Two Pneumatic Slide Gate Valves (IECEX Coils) for Automated weigh hopper refilling
  • Two 800L Stainless Steel 304 Weigh Hoppers on Load Cells with Weight Indicators
  • Two RV02.20 Rotary Valves with IECEX Hazardous Area Motor for loss in weight feeding
  • Two Pneumatic Control Panels for simplicity of the compressed air controls.
Brewery Grain Bulk Bag Unloaders    Brewery Wheat Malt and Rolled Wheat Bulk Bag Unloaders



Flap Diverter Valves for Powders and Granules

Filquip is an Australian distributor of Vertical Gravity Fed Flap Diverter Valves for Powders and Granules. We supply these gravity Diverter valves in a wide range of sizes and orientations including 2-way and 3-way types and Symmetric (Y diverter) and A-Symmetric (K Diverter) versions.

Our Diverter valves provide safe and reliable control of product flow from hoppers, silos, tanks and mechanical transport systems. Our diverters are suitable for abrasive powders and granules with optional finishes in Painted Mild Steel, Hardox hard wearing steel, Stainless Steel 304 and Stainless Steel 316.

Filquip has recently specifed and supplied a two new 400mm Square 2-way 45 deg Symmetric (Y style) diverter valves with Hardox wear resistant body and Hardox diverter flap. The units are Pneumatically Actuated with 24VDC Coils, and PNP 3-wire Limit switches.

Hardox wear resistance building products diverter valve    Flap Diverter Valves for Powders and Granules




Silo Pressure Relief Valves

Filquip has been specifying and supplying Silo pressure relief valves for over 20 years for all types of powders and granular materials.

The WAM VHS and VCP Silo Pressure relief valves provide a safety net when abnormal pressure conditions endanger the silo structure. With hundreds of thousands installed worldwide, WAM Pressure Relief Valves are the standardised reliable solution for almost any silo application.

We have a number of helpful Filquip Videos on this page to explain the operation, setting up and maintenance of our Silo Pressure Relief Valve Range.


WAM VHS-B Membrane Silo Pressure Relief Valves (PRV)

Filquip supply WAM VHS membrane silo pressure relief valves to provide a safety net when abnormal pressure conditions endanger the silo structure.

  • Excess Pressure up to 900 mm H2O at a flow rate of 5,000m³/hour (0.09 Bar or 1.3 PSI at 2,950 cfm).
  • Vacuum/Negative Pressure up to -50 mm H2O at a flow rate of 1,900m³/hour (-0.005 Bar or -0.07 PSI).
  • Stainless Steel 304 Casing with Mild Steel or Stainless Steel Upstand to connect to your silo.
  • Casing Diameter 273mm
  • Available with Duct to Ground kit.
  • Food Grade Versions Available.

Open VHS Stainless Steel Pressure Relief Valve Brochure


WAM VCP Spring-Loaded Silo Pressure Relief Valves (PRV)

Filquip supply WAM VCP spring loaded silo pressure relief valves to handle sudden excess or suction pressures that can develop in the silo, hopper or bin.

  • Excess Pressure up to 800 mm H2O at a flow rate of 13,000m³/hour (0.05 Bar or 0.72 PSI at 7,650 cfm).
  • Vacuum/Negative Pressure up to -100 mm H2O at a flow rate of 1,900m³/hour (-0.01 Bar or -0.14 PSI).
  • Painted Carbon Steel or Stainless Steel 304 Casing with Mild Steel or Stainless Steel Upstand to connect to your silo.
  • Casing Diameter 273mm (10 inch) or the larger 356mm (14 inch) model.
  • Available with inductive sensor for an output signal when the valve is activated.
  • Food Grade Versions Available.

Open VCP Spring Loaded Pressure Relief Valve Brochure


WAM VHS-C Polymer Membrane Silo Pressure Relief Valves (PRV)

Filquip supply WAM VHS-C Polymer membrane silo pressure relief valves to ensure the filling of a silo does not allow abnormal pressure conditions to endanger the silo structure.

  • Excess Pressure up to 500 mm H2O at a flow rate of 5,000m³/hour (0.05 Bar or 0.72 PSI at 2,950 cfm).
  • Vacuum/Negative Pressure up to -50 mm H2O at a flow rate of 1,900m³/hour (-0.005 Bar or -0.07 PSI).
  • Polymer Casing with Mild Steel or Stainless Steel Upstand to connect to your silo.
  • Casing Diameter 273mm (10 inch).
  • Counterweight system never in contact with dust.
  • Special properties of membrane and elbow prevent clogging and formation of material crusts.
  • Available with Duct to Ground kit.
  • Food Grade Versions Available.
  • Available with inductive sensor for an output signal when the valve is activated.

Open VHS-C Polymer Pressure Relief Valve Brochure




Silo Filling protection systemSilo Overfill Protection System

Filquip can supply a tailored silo overfill protection system to suit any system, to prevent dangerous over pressurisation and over filling, while eliminating dust emissions.

  • Avoid damage to silo and accessories.
  • Reduce the risk of air pollutions.
  • Eliminate the risk of filling the incorrect silo.
  • Start and stop the filter cleaner automatically.
  • Systems can be tailored to suit applications including the need for Pressure monitoring, Over pressure or vacuum release valves, Fill control, Dust control and Operator destination selection panel.

Open Silo Overfill Protection System Page

Brewery Malt Grain Pneumatic Conveying System

Filquip has recently delivered a new brewery lean phase Pneumatic conveying system to transfer bulk malt grain from new storage silos at the front of the Brewery a distance of 80m to the storage hoppers before the grain mill and mash in system. Filquip designed the system to run underneth the site access road through an existing pit with covers and then over the roof of the plant to the destination.

The following Filquip equipment package was provided for this Brewery Pale Malt Grain Pneumatic Conveying System:

  • 7.5Kw Side Channel Blower with Filtered air Intake.
  • 20 Rotary Valve with IECEX Hazardous Area Motor.
  • 80m of SS304 76.1mm Conveying Tubework, Bends, Clamps and Brackets.

Brewery Pale Malt Grain Pneumatic Conveying System

Brewery Pale Malt Grain Pneumatic Conveying     Brewery Grain Pneumatic Conveying
